Dreusicke offers the fine tools you will need for the maintenance and repair of office machines, computers, electronic and/or fine-mechanical devices. (for commercial users only)
- Temperature measurement range: -20 °C to +550 °C
- Thermal resolution: 96 x 96 (9,216 measuring points)
- Upscaled resolution: 240 x 240 (57,600 measuring points) via Enhanced IR image optimization technology
- Thermal sensitivity: < 0.05 °C (50 mK)
- 3 image modes (thermal, fusion and optical) and 7 color palettes for displaying the thermal image
- High frame rate of 25 Hz for smooth and jerk-free display of thermal images
- Optical camera with 640 x 480 pixels for more detailed information and assignment of the thermal image
- Wide-angle lens (50° x 50°) for capturing large areas
- Alarm function at high temperatures
- 2.4" (6.1 cm) color LCD screen
- Integrated 4 GB flash memory for 30,000 images
- Li-ion battery and USB Type C interface
Practical, efficient and robust
- Automatic measurement of hotspot (max), coldspot (min) and center spot (image center temperature)
- Merged images from thermal image and optical image for more details and contour sharpness
- Laser beam for quickly targeting the target object
- Single image recording and planned recording with adjustable time interval (hh.mm.ss) and number of images
- Alarm function at high temperature
- Powerful Li-ion battery (3,350 mAh) with up to 8 hours of continuous running time
- Dust and splash-proof housing (IP 54) with 2 m drop test height
- Compact pistol shape and intuitive Operation
Technical data:
Display: 2.4" color LCD screen (240 x 320 points)
Measuring range / accuracy: -20 °C to 550 °C / ± (2 °C or 2 %)
Radiometric thermal image resolution: 96 x 96 (9,216 points)
Enhanced IR thermal image resolution: 240 x 240 (57,600 points)
Thermal sensitivity (NEDT): < 0.05 °C (50 mK) @ 25 °C
Refresh rate: 25 Hz
Optical image resolution / IFOV value: 0.3 MP (640 x 480 points) / 8.89 mrad
Automatic measurements: MAX, MIN, CENTER temperature
Capture mode: Single image, scheduled recording with time interval (hh:mm:ss) and number of images
Mirror device display on PC: Via USB cable using UVC protocol
Battery / charge: Li-ion battery 3350 mAh / USB Type C
Flash memory / file format: 4 GB / radiometric JPEG
Storage capacity: Approx. 30,000 images
Interfaces: USB Type C
Protection class: IP 54 (dust/splash protection)
Drop test height: 2 m
Dimensions: 196 x 78 x 59 mm
Weight: 290 g
Article number: 050530
Scope of delivery:
- Thermal imaging camera TC20
- Hand strap
- USB Type C connection cable
- Quick start guide
Bosch
Lieferumfang:
- GRO 12V-35 Akku-Multirotationswerkzeug
- L-BOXX 102 mit 1/2 L-BOXX-Einlage
Schuelke
Load capacity: 180 kg
Platform: 670 x 465 mm
Handle height: 895 mm
Dimensions: 770 x 465 x 895 mm
740 x 465 x 265 mm (folded)
Wheels: 2 swivel and 2 fixed castors, each Ø 100 mm
Rim made of polypropylene, bandage made of TPE
Optionally with Spannfix system (must be ordered separately): Order no. 4040-SPANNFIX
Also available as a version without brake, see order no. 4040-D or in XL version, order no. 4040-XL or 4040-XLB (with brake)
Part list
Wiederaufladbare Taschenlampe mit Fokussierfunktion (Advanced Focus System)
Unkomplizierte Bedienung mit einem Knopf
Nachhaltig: Einsatz von 75 % recyceltem Aluminium9 sowie 7 Jahre Garantie (bei Registrierung)
Wiederaufladbar per USB-C (Ladekabel nicht enthalten)
Element-proof: Hoher Staub- und Wasserschutz (IP68)
Leuchtweite (in m) 320
Max. Lichtstrom (in lm) 1200
CRI 70
Lichtquellen Farbtemperatur 6000 - 7500
Attributes: Boost/Power/Mid power/Low power
Lichtstrom (in lm) 1200/700/300/25
Leuchtweite (in m) 320/240/160/45
Laufzeit (in h) -/2.5/7.5/65
Akku im Lieferumfang enthalten.
Part list
Wera
Part list
Dreusicke
Part list
